Introduction

317L austenitic stainless steel plate is a low carbon stainless steel plate (≤0.03% C) with high molybdenum content (3-4%), offering high corrosion resistance superior to 316L. As a 317L molybdenum stainless steel plate, its elevated Mo level significantly enhances pitting resistance and crevice corrosion resistance, making it ideal for severe corrosion environments. Manufactured to ASTM A240 (UNS S31703), this 317L corrosion resistant stainless steel plate is widely used in the chemical industry, marine environment, flue gas desulfurization (FGD) systems, pulp and paper industry, and pharmaceutical equipment—wherever chlorides, acids, or high-temperature corrosive media challenge standard grades. For critical service, 317L high corrosion resistant stainless steel plate for marine use and UNS S31703 stainless steel plate for flue gas desulfurization are preferred choices.

Chemical components(%)

Mechanical properties

Physical properties

317L Stainless Steel Plate Available Products and Standard

1. GB/T 4237

(Stainless Steel Hot-Rolled Sheets and Strips)

Material Grade: 022Cr19Ni13Mo3 (UNS S31703 / 317L)

Type:

• 317L stainless steel Sheet

• 317L stainless steel Plate

• 317L stainless steel Strip

Size Range:

• Thickness: 0.5 – 200 mm (hot‑rolled or cold‑rolled)

• Width: up to 4200 mm

• Length: customised

Surface: Annealed, Pickled, Bright, No.1, 2B, BA, No.4, Mirror (polished)

Testing: Chemical analysis, tensile test, hardness test, flattening test (for strip), intergranular corrosion test, pitting corrosion test, dimensional inspection

2. ASTM A240 / ASME SA240

(Standard Specification for Pressure Vessels and General Applications)-

Grade: 317L / UNS S31703 – 317L molybdenum stainless steel plate with high molybdenum content (3.0–4.0%)-

Type:

• SS 317L Plate

• SS 317L Sheet

• SS 317L Strip

Size Range:

• Thickness: 0.2 – 150 mm (hot‑rolled or cold‑rolled)

• Width: up to 3500 mm (customised)

• Length: up to 12000 mm (customised)

Surface: Annealed, Pickled, Bright, No.1 (hot‑rolled), 2B (cold‑rolled), BA, No.4, Mirror (polished)

Testing: Chemical analysis, tensile test (Rm: 500–700 MPa, Rp0.2: >200 MPa), elongation test (>40%), hardness test (≤187 HB), flattening test, hydrostatic test, pitting corrosion test, crevice corrosion test, intergranular corrosion test (for severe corrosion environment validation), dimensional inspection

3. EN 10088‑2

(Technical Delivery Conditions for Sheet/Plate and Strip of Corrosion Resisting Steels for General Purposes)-

Grade: X2CrNiMo18‑15‑4 / 1.4438 (EN equivalent of UNS S31703 / 317L)-

Type:

• 317L stainless steel Hot‑rolled plate

• 317L stainless steel Cold‑rolled sheet

• 317L stainless steel Strip

Size Range:

• Thickness: 0.5 – 200 mm (hot‑rolled or cold‑rolled)

• Width: up to 3500 mm (customised)

Surface: Annealed, Pickled, Bright, 1D, 2B, 2D, BA

Testing: Chemical composition verification, mechanical test (tensile, hardness), pitting corrosion resistance test, crevice corrosion resistance test, intergranular corrosion test (per EN ISO 3651‑2), flattening test (for strip), eddy current test (optional), dimensional inspection

4. JIS G4304

(Hot‑Rolled Stainless Steel Plate, Sheet and Strip)

Grade: SUS317L (Japanese equivalent of UNS S31703 / 317L)-

Type:

• SS 317L Hot‑rolled stainless steel plate

• SS 317L Sheet

• SS 317L Strip

Size Range:

• Thickness: 2.0 – 150 mm (hot‑rolled)

• Width: up to 2000 mm (customised)-

Surface: Annealed, Pickled, No.1 (hot‑rolled finish)

Testing: Chemical analysis (carbon ≤0.030%, molybdenum 3.0–4.0%), tensile test, hardness test (≤187 HB), flattening test, pitting corrosion test, crevice corrosion test, intergranular corrosion test, dimensional inspection

Applications

(1)Chemical industry – ASTM A240 317L austenitic stainless steel plate (low carbon, high molybdenum content 3-4%) resists pitting and crevice corrosion in aggressive acids and hot chlorides, ideal for reactors and storage tanks.

(2)Marine environment – As a 317L high corrosion resistant stainless steel plate for marine use, it withstands seawater and salt spray, outperforming 316L in boat fittings, piers, and offshore platforms.

(3)Flue gas desulfurization (FGD) – UNS S31703 stainless steel plate for flue gas desulfurization handles severe corrosion from sulfurous acids and chlorides, used in absorber towers, ducts, and dampers.

(4)Pulp and paper industry – 317L corrosion resistant stainless steel plate resists bleaching chemicals and liquor, specified for digesters, bleach washers, and bleaching towers.

(5)Pharmaceutical equipment – 317L low carbon stainless steel plate provides weld integrity and high purity surface, chosen for clean-room vessels and process piping where aggressive cleaning agents are used.

(6)Severe corrosion environment – Whether for chemical, marine, or FGD service, 317L stainless steel plate with high molybdenum content delivers superior pitting resistance and crevice corrosion resistance, extending equipment life in the most demanding conditions.

MONO Group is one of 317L Stainless Steel Plate Manufacturer&Supplier&Wholesaler from China,We can supply ASTM /DIN/ISO/GB stndard high quality alloy plate,sheet,round bar,tube.pipes,fittings,flange,pls contact us freely for your RFQ to info@monokj.com
