Introduction

A stainless steel equal angle or stainless steel unequal angle is a stainless steel structural angle produced as a corrosion resistant stainless steel angle via hot rolled stainless steel angle or cold‑forming. Two primary configurations are available: equal stainless steel angle (both legs identical length) and unequal stainless steel angle (legs of different lengths), both supplied as L shape stainless steel angle. Common material grades include 304 stainless steel angle, 316 stainless steel angle, 316L stainless steel angle bar, and duplex stainless steel angle. These profiles offer high strength, excellent weldability, and good corrosion resistance for structural and architectural applications.

Applications

(1)Construction – Stainless steel angle for building frames, support brackets, door frames, and window trims provides load‑bearing capacity and long‑term durability without painting, with 304 grade for general interior use.

(2)Structural support – Stainless steel equal angle for equipment skids, platform walkways, conveyor supports, and machinery bases offers high rigidity and weldability, with 316L grade for chemical or marine environments.

(3Industrial shelving – Stainless steel unequal angle for storage racks, pallet racks, and workbenches combines strength with space‑efficient design, resisting corrosion in warehouses and food processing plants.

(4)Marine – Stainless steel angle for boat building, dock rails, offshore platform handrails, and ship interior fittings resists saltwater corrosion, with duplex or 316L grades preferred for splash zone service.

(5)Architectural – Stainless steel L shape angle for curtain wall supports, stair stringers, balcony railings, and decorative trims provides a clean aesthetic and corrosion resistance, often polished to a No.4 or mirror finish.

Stainless Steel Angle Available Products and Standard

1. ASTM A276 / A479

(Standard Specification for Stainless Steel Bars and Shapes / for Pressure Vessels)

Type:

• Stainless Steel Equal Angle

• Hot rolled stainless steel angle

• unequal stainless steel angle

• L shape stainless steel angle

• duplex stainless steel angle

Size Range:

Equal angle leg lengths: 20×20 mm – 250×250 mm

Unequal angle leg lengths: 20×30 mm – 100×150 mm

Thickness: 2 – 20 mm

Length: 3000 – 12000 mm (random or fixed)

Surface: Hot rolled (descaled), Annealed, Pickled, Bright (cold drawn optional)

Testing: Chemical analysis, tensile test (Rm ≥515 MPa for 304, ≥485 MPa for 316L; duplex: ≥620 MPa), elongation (≥30% for austenitic, ≥25% for duplex), hardness (≤90 HRB for 304/316, ≤32 HRC for duplex), flattening test (leg squareness), dimensional inspection (per ASTM A484 – straightness, twist, leg length tolerance)

2. EN 10088‑3

(Technical Delivery Conditions for Semi‑finished Products, Bars, Rods and Sections)

Type: Hot Rolled Stainless Steel Angle

Size Range:

• Equal angle: 20×20 – 200×200 mm (thickness 2 – 20 mm)

• Unequal angle: 20×30 – 100×150 mm (thickness 2 – 15 mm)

• Length: 3000 – 12000 mm (custom up to 18000 mm)

Surface: Hot rolled, Annealed, Pickled, Bright

Testing: Chemical analysis, tensile test (Rm 500‑700 MPa for 1.4301, Rp0.2 ≥200 MPa; duplex: Rm 650‑850 MPa, Rp0.2 ≥450 MPa), elongation (≥35% for austenitic, ≥25% for duplex), flattening test, ultrasonic test (for heavy sections), dimensional inspection (per EN 10056‑1/2)

Standard Size(mm)

MONO Group is one of Stainless steel Angle Manufacturer & Supplier & Wholesaler from China, We can supply ASTM / DIN / ISO / GB stndard high quality alloy plate, sheet, round bar, tube, pipes, fittings, flange, pls contact us freely for your RFQ to info@monokj.com
